Features of Stretch Wrap Machine:
The Pallet Wrapping Machine adopts an open strap channel, allowing the strap channel (sword groove) to automatically pass through the structural holes of the pallet, securing both the product and the pallet together with the strapping band.
The Pallet Wrapper is designed to accommodate strapping bands with an inner diameter of 406mm. A larger reel inner diameter helps reduce the curvature of the strapping band, improving the success rate of band feeding in the Strapping Machine. If a 200mm inner diameter specification is required, special indication is needed, and customization is available.
The Cargo Wrapping Machine adopts a side-strapping high-tension head structure, with strap tension adjustable between 20-250KG via a touchscreen interface. It is suitable for PP and PET strapping bands, with optional main unit travel distances of 400mm or 600mm.
Open Strap Channel:
Can automatically pass through the structural holes of the pallet.
Strap Reel Component:
The EOL Stretch Wrapping Machine configuration accommodates strapping bands with an inner diameter of 406mm. A larger reel inner diameter helps reduce the curvature of the strapping band, improving the success rate of band feeding in the strapping machine. If a 200mm inner diameter specification is required, special indication is needed, and customization is available.
Head Component:
Adopts a side-strapping head structure with strap tension of 20-250KG. The Automatic Pallet Strapping Machine is suitable for PP and PET strapping bands, with a standard main unit travel distance of 350mm.
Control Component:
End of Line Pallet Wrapper The standard configuration uses "Siemens" PLC, "Xinje" HMI (Human-Machine Interface), and "Schneider" contactors.
Arch Frame Component:
The standard arch frame has an effective inner diameter of 1400W*1450H and can be custom-made according to pallet dimensions.
Optional Configurations:
Pressure mechanism, various types of conveying mechanisms.
