Dual Drive Carton Sealer

Get Latest Price

Contact Now

Product Description

The Dual Drive Carton Sealer utilizes dual-side synchronous belt drive, offering smooth operation and flexible adjustment. It is widely used in medium to small‑batch packaging lines across industries such as e‑commerce, daily chemicals, food, pharmaceuticals, and books. The Case Sealer supports integration with various brands of fully automatic strapping machines, enabling continuous “sealing + strapping” operations, effectively enhancing packaging efficiency and integration.

Parameters of Automatic Case Sealing Machine

Supply Voltage: AC220V / 50Hz

Power: 360W

Conveyor Speed: 20 m/min

Applicable Tape: 48mm, 60mm, 75mm

Drive Method: Dual-side synchronous belt drive

Applicable Sealing Dimensions:

Minimum: L250 × W150 × H120 mm

Maximum: L600 × W500 × H500 mm

Overall Dimensions (L × W × H): 2358 × 915 × 1750 mm

Machine Weight: Approx. 200 kg

Features of High‑Speed Carton Sealer

Rational Structural Design

The End Of Line Case Sealer is simple and elegant in appearance, with a robust mechanical structure for easy maintenance and cleaning.

Multi‑functional Integrated Operation

Completes automatic top‑flap folding, top‑bottom “I‑type” sealing, and strapping in one go, with customizable strapping frequency.

Advanced Drive Method

The EOL Carton Sealer adopts dual‑side synchronous belt drive for stable conveying, preventing carton misalignment or jamming.

Flexible Carton Adjustment

Manual adjustment of width and height allows quick adaptation to cartons of different specifications.

Versatile Usage Modes

The Dual Drive Box Sealing Machine offers adjustable table height, enabling standalone operation or integration into packaging lines for collaborative use.

Strong Compatibility

Can be linked with multiple brands of fully automatic strapping machines to build continuous packaging systems.

Supports Non‑standard Customization

Custom Case Sealer In addition to standard specifications, customized solutions can be provided based on user product dimensions, speed requirements, and functional combinations.
