Product Description
Horizontal Motion Case Packer adopts the working principle of horizontal grabbing and precise placement, enabling high-speed automated packing of bottles, cans, boxed products, bagged materials, and industrial components. It is widely applicable to production lines in industries such as food and beverage, daily chemicals, pharmaceuticals and healthcare, and electronic components.
Performance Advantages of Case Packer
Efficient and Stable Operation
The Robotic Case Packer features a servo drive system and precise pneumatic control, ensuring fast and smooth grabbing movements with accurate and reliable positioning. The maximum working speed can reach up to 3,300 cases per hour (approximately 55 cases per minute), with an extremely low error rate even during high-speed operation, meeting the demands of continuous high-intensity production.
Flexible and Versatile Configuration
The number of grabbing heads offers a variety of options ranging from 1 to 12. The Linear Motion Case Packer can adjust based on product size, shape, and arrangement quantity. Modes can be freely configured through the control system, adapting to single-layer flat layouts, multi-layer stacking, and various complex arrangement combinations.
Sturdy and Durable Structure
The High-Speed Case Packing frame is constructed from high-strength steel, offering strong resistance to humid and dusty environments, ensuring stable operation and a long service life.
Intelligent and User-Friendly Control
Equipped with a high-definition touchscreen human-machine interface, parameter settings are intuitive and straightforward, supporting the storage and one-touch recall of multiple product packaging formulas. Functions include automatic material detection, shortage warnings, and production data statistics.
Energy-Efficient and Environmentally Friendly
The Automated Case Packer utilizes high-efficiency drive motors and an intelligent pneumatic system, significantly reducing energy consumption. The equipment operates with low noise, and air consumption can be controlled between 20–60 cubic meters per hour depending on the configuration, complying with the environmental standards of modern green factories.
Case Packer for Food Industry - Technical Specifications
Power Supply:Three-phase AC380V, 50Hz
Total Power: 7-15kW
Available configurations: 7-10kW, 0-12kW, or 12-15kW
Air Source Pressure:0.6 - 0.8 MPa
Working Speed: Carton Packaging Machine Three configurations available:12-15 cases/minute、20-30 cases/minute、40-55 cases/minute
Gripping Head Options: Basic: 1-3 heads、Standard: 4-6 heads、High-speed: 8-12 heads
Air Consumption:20-40 m³/h、30-40 m³/h、30-60 m³/h
Application Industries: Food and beverage, daily chemicals, pharmaceuticals and healthcare, electronics manufacturing, automotive components, and other industries.
